详细介绍
| | Description | Unit | Size |
| CAPACITY 性能 | BETWEEN CENTRE LENGTH 中心距 | mm | 425 |
| MAXIMUM MACHINING DIA zui大加工直径 | mm | 290 | |
| MAXIMUM TURNING LENGTH zui大切削直径 | mm | 400 | |
| STANDARD CHUCK SIZE 标准卡盘尺寸 | mm | 200 | |
| STANDARD CHUCKING CYLINDER 标准液压油缸 | | P-110 | |
| CNC SYSTEM | CNC SYSTEM 系统 | | Fanuc 0I mate - TC |
| SPINDLE 主轴 | SPINDLE TYPE 主轴型号 | | Cartridge |
| SPINDLE NOSE 主轴头 | Size | A2-5 | |
| SPINDLE BORE 主轴通孔直径 | mm | 47 | |
| STANDARD BAR CAPACITY 标准棒料直径 | mm | 25 | |
| FRONT BEARING BORE 前轴承孔 | mm | 80 | |
| STD SPINDLE SPEED 标准主轴转速 | rpm | 4000 | |
| POWER 动力 | SPINDLE MOTOR POWER CONTINUOUS 主轴电机额定功率（连续运转额定） | KW | 5.5 |
| SPINDLE MOTOR POWER INTERMITTENT （15 MIN） 主轴电机额定功率（15分钟运转额定） | Kw | 7.5 | |
| FULL POWER RANGE 功率范围 | rpm | 1333-3000 | |
| SPINDLE MOTOR MODEL 主轴马达型号 | | Fanuc; Beta 6I | |
| TOOLING * | TURRET 刀塔 | | BTP-80 |
| NUMBER OF TOOLS MAX zui多装夹*数量 | | 8 | |
| NUMBER OF STATIONS 工位数 | | 8 | |
| A/F OF TURRET DISC 多边形刀盘直径 | mm | 280 | |
| MAXIMUM BORING BAR DIA. zui大镗杆直径 | mm | 40 | |
| OD TURNING TOOL SIZE *横截面 | mm | 25 x 25 | |
| X-AXIS | Axes Motor Model 驱动轴马达型号 | | Fanuc; Beta 8is |
| X-AXIS-GUIDEWAYS X轴导轨 | | Hardened and Ground strip | |
| X-AXIS STROKE X轴行程 | mm | 150 | |
| X-AXIS RAPID RATE X轴快速移动速度 | m/min | 20 | |
| X-BALL SCREW DIAANDPITCH X轴滚珠丝杆直径和间距 | mm | 32 x 10 | |
| X-MOTOR TORQUE X轴马达的扭矩 | N.m | 8 | |
| Z-AXIS | Axes Motor Model 坐标轴马达型号 | | Fanuc; Beta 8is |
| Z-AXIS-GUIDEWAYS Z轴导轨 | | Hardened and Ground strip | |
| Z-AXIS STROKE Z轴行程 | mm | 400 | |
| Z-AXIS RAPID RATE Z轴快速移动速度 | m/min | 20 | |
| Z-BALL SCREW DIA AND PITCH Z轴滚珠丝杆直径和间距 | mm | 32 x 10 | |
| Z-MOTOR TORQUE Z轴马达的扭矩 | N-m | 8 | |
| Tailstock 尾架 | TAILSTOCK QUILL TRAVEL尾架套筒行程 | mm | 100 |
| TAILSTOCK BASE TRAVEL 尾架底座行程 | mm | 235 | |
| TAILSTOCK THRUST （MAX） 尾架的zui大推力 | daN | 300 @12 kg/cm2 | |
| TAILSTOCK QUILL DIA. 尾架套筒直径 | mm | 80 | |
| QUILL TAPER 套筒内锥孔 | | MT-4 | |
| TAILSTOCK CENTRE TYPE 尾架*型号 | | Add On | |
| MISC. | COOLANT TANK CAPACITY 冷却箱的容量 | l | 110 |
| SYSTEM PRESSURE （MAX） 系统zui大压力 | kg / cm2 | 30 | |
| HYDRAULIC PUMP CAPACITY液压泵系统的容量 | l/min | 12 | |
| POWER PACK TANK CAPACITY动力机箱容量 | l | 45 | |
| OVERALL MACHINE DIMENSIONS机床总尺寸 | mm | 2200 X 1700 X 1775 | |
| OVERALL MACHINE WEIGHT机床总重量 | kg | ~ 3800 |
